BioDigitalPC® R3
BioDigitalPC® R3
Overview
Specs
Documentation
Arnouse Digital Device’s newest docking station for the BioDigitalPC® Ecosystem uses a minimalistic approach to our data, power and video signals. The R3 can be used for integration into larger systems, such as a laptop, tablet, television or even a supercomputer.
Proudly made in the USA. TAA Compliant.
- SKU: ADDC-R3-I
- Size: 63mm x 27mm x 6mm (Without Headers)
- Power: 5VDC Input
- System Includes:
- (1) USB 3.0 Header
- (4) USB 2.0 Headers
- (1) DisplayPort++ Header
- PCIe x1 Header (External 3.3V & 12V Required)
- 5V Fan Header
- System On/Off Header
- Spare Microcontroller GPIO Pin Header
- PCIe Voltage Enable Output Pin 0.05″ (for Microcontroller Programming Pins)
- BioDigitalPC® 100-pin Docking Connector
- (3) 4mm Mounting Holes
- (2) 3mm Mounting Holes
- Headers are standard 0.1″ pitch
