BioDigitalPC® M7
BioDigitalPC® M7
Overview
Specs
Documentation
Drivers
ADDC has developed a micro-form factor docking station for use within integrated products such as monitors, tablets, TVs and micro client setups. Utilizing a small energy footprint, the M7 is the easiest way to integrate into larger platforms while maintaining standard connections.
Proudly made in the USA. TAA Compliant.
Green by Design
BioDigitalPC® products encompass a revolutionary computing system which allows for maximum flexibility with minimum footprint, weight and energy consumption.
- SKU: ADDC-M7-I
- Size: 116mm x 46mm x 20mm
- Power: 12VDC Input (2.5mm Power Jack)
- System Includes:
- (1) USB 3.0
- (4) USB 2.0
- (1) Ethernet Port (10/100/1000)
- (1) Mini-DP++ (HDMI capable)
- PCIe x1 Connector (Optional)
- Reset and System On/Off Headers
- 4A DC-DC Converter (For 3.3V req. in MiniDP & PCIe x1)
- 5V & 12V Fan Headers
- Red 5V & 12V Power LED Indicator and Header
- Green Card Detect LED Indicator and Header
- BioDigitalPC® 100-pin Docking Connector
- (3) 4mm Mounting Holes
- External 12V PCIe Power Header
- VMWare compatible
- Headers are standard 0.1″ pitch
